Bare Die Tape and Reel

Systemation Euro provides bare die tape and reel UK services for wafer level CSP, WLCSP, flip chip and die package devices. We take unpackaged semiconductor die from wafer, film frame, waffle pack or loose format and place them into EIA-481-D compliant carrier tape, ready for direct SMT line-feed. Based in Northampton, with shipping available across the UK and Europe.

Our bare die tape and reel service is available standalone or combined with IC programming, laser marking, dry packing and BGA laser reballing for a complete component finishing solution under one roof.

Bare die tape and reel often forms part of a wider finishing process alongside our IC programming and laser reballing services, with dry packing and carrier tape options available depending on the package format you need.

Our Bare Die Tape and Reel Capabilities

Input Formats Accepted

Wafer (6″, 8″ and 12″), film frame, waffle pack, and loose die. All formats processed through automated die handlers with integrated vision inspection.

Die Size Range

0.5mm square to 12mm square, suitable for the full range of CSP, WLCSP, micro-BGA, bumped die and flip chip packages used in automotive, defence, aerospace and medical applications.

Minimum Die Thickness

Processing down to 60 micron thickness, with precision handling throughout to prevent cracking or chipping of ultra-thin devices.

Supported Processes

Film Frame Mount (6″, 8″ and 12″ wafers)
Wafer to Tape & Reel
Waffle Pack to Tape & Reel
Wafer to Waffle Pack
Inspection for defects
Packaging and Distribution

Substrate Materials

Silicon, glass, ceramic and FR4-based wafer level devices all supported.

EIA-481-D Compliance

All bare die tape and reel processing is compliant to the EIA-481-D standard throughout.

Controlled Environment

ESD, humidity and temperature controlled production environment, with cleanroom processing available for devices requiring a protected environment.

Inspection

Automated inspection of die and flip chip for cracking, chipping, bump coplanarity and orientation, built into the taping process.

Traceability

Full lot traceability and documentation, essential for aerospace, defence and medical programmes requiring complete process records.

UK-Based Service

Based in Northampton, central England, for faster turnaround for UK and Midlands manufacturers, with Europe-wide shipping available. See our UK specialist page for more on why manufacturers choose UK-based processing.

About Our Bare Die Tape and Reel Process

Bare die tape and reel is the process of taking unpackaged semiconductor die, supplied as diced wafer on film frame, in waffle packs, or as loose die, and placing them precisely into carrier tape for automated SMT pick-and-place assembly. This allows manufacturers to use bare die and wafer level packages directly on standard SMT lines without manual handling, reducing placement errors and protecting fragile devices throughout the supply chain.

Systemation Euro uses automated die handlers with high-resolution vision systems to place, inspect and reel bare die to customer specification. Every reel is produced to EIA-481-D standard with customer-defined pitch, pocket dimensions and reel format, ready for direct line-feed.

Typical applications include automotive sensor packaging, defence and aerospace component supply chain processing, medical device assembly, RFID and cellphone component finishing, and redistribution of wafer level CSP product for contract electronics manufacturers.
